| SINGLE
& MULTICORE CABLES (SCREENED AND UNSCREENED TYPES) UL 2464
單芯或多芯電線(有屏蔽或無屏蔽) UL 2464 |
|
Conductor 導體 |
: |
Solid or stranded tinned annealed copper wire 銅線 |
| PVC
Equipment wires
聚氯乙烯電線 |
: | PVC
compound temperature range -15 to +85
聚氯乙烯工作溫度為 -15 至 +85 |
TABLE 1 : SINGLE CORE
單芯電線
 |
||||||
|
Number
and size of wires 電線的
數量和大小
(mm) |
|
Mean
radial
insulation thickness 絕緣厚度 (mm)
|
|
Overall
diameter 直徑 (mm)
|
|
|
||||||
|
1/0.6
1/1.13 16/0.2 24/0.2 32/0.2 63/0.2 |
|
0.45
0.45 0.60 0.60 0.60 0.60 |
|
1.60
2.15 2.25 2.45 2.65 3.15 |
|
|
||||||
TABLE 2 : MULTICORE CABLE
多芯電線
Stranded tinned copper wire, PVC insulated and sheathed with cores bound in polyester tape.
銅絞電線,聚氯乙烯絕緣,聚氯乙烯護套
|
||||||||
|
Number
of conductors 導體數目
|
|
Number
and
size of wire 電線的
數目和大小
(mm) |
|
Overall
diameter 直徑 (mm) |
|
With
additional
tinned copper wire braid O.D. 附加錫後銅線的外徑
(mm)
|
|
|
||||||||
|
2
3 4 6 8 9 10 12 15 18 25 25 36 50 60 2 3 4 6 10 12 18 25 36 60 |
|
7/0.20
7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.20 7/0.10 7/0.20 7/0.20 7/0.20 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 16/0.2 |
|
3.60
3.80 4.60 4.80 5.10 6.60 6.90 6.40 8.00 7.70 9.00 6.60 10.10 12.00 12.80 5.50 5.80 6.30 7.30 11.30 9.50 11.00 13.10 16.10 19.70 |
|
4.1
4.3 4.6 5.9 6.3 7.2 8.5 9.8 11.2 13.0 13.8 6.5 6.8 7.3 8.3 10.5 12.0 14.1 |
|
|
||||||||
